Product Details
Place of Origin: Beijing, China
Brand Name: Huiyu
Certification: ce
Model Number: BT100F-1A
Payment & Shipping Terms
Price: $355.00/sets >=1 sets
Packaging Details: 1 peristaltic pump in 1 carton , with foam plastic
Supply Ability: 100 Set/Sets per Week
Warranty: |
1year |
Customized Support: |
OEM |
Application: |
Food And Beverage Industry, Pharmaceutical Industry, Wastewater Treatment, Water Treatment Solutions, Liquid Filling |
Horsepower: |
30w |
Power Source: |
Electric |
Pressure: |
0.2Mpa, 0.2mpa 2bar |
Structure: |
Peristaltic Pump |
Cable Length: |
1.5m |
Outlet Size: |
6.4mm |
Voltage: |
AC110v Or 220v |
Power: |
30w |
Motor: |
Stepper Motor |
Product Name: |
Peristaltic Pump |
Brand: |
Huiyu |
Flow Rate: |
0.07-380ml/min |
Motor Speed: |
0.1-100rpm |
Power Supply: |
AC 220V ±20% |
Dimension(LxWxH): |
243X151X157 (mm) |
Drive Weight: |
3.5 Kg |
Port: |
Beijing,Tianjin,Qingdao |
Warranty: |
1year |
Customized Support: |
OEM |
Application: |
Food And Beverage Industry, Pharmaceutical Industry, Wastewater Treatment, Water Treatment Solutions, Liquid Filling |
Horsepower: |
30w |
Power Source: |
Electric |
Pressure: |
0.2Mpa, 0.2mpa 2bar |
Structure: |
Peristaltic Pump |
Cable Length: |
1.5m |
Outlet Size: |
6.4mm |
Voltage: |
AC110v Or 220v |
Power: |
30w |
Motor: |
Stepper Motor |
Product Name: |
Peristaltic Pump |
Brand: |
Huiyu |
Flow Rate: |
0.07-380ml/min |
Motor Speed: |
0.1-100rpm |
Power Supply: |
AC 220V ±20% |
Dimension(LxWxH): |
243X151X157 (mm) |
Drive Weight: |
3.5 Kg |
Port: |
Beijing,Tianjin,Qingdao |
| Pump head | model | Available tubing | flow rate range (ml/min) |
| YZ15-1A | 13#,14#,19#,16#,25#,17#,18# wall thickness 1.5mm | 0.07-380ml/min | |
| YZ25-1A | 15#,24# wall thickness 2.5mm | 0.2-270ml/min | |
| DG-1A | ID≤3.17mm; wall thickness 0.8-1.0mm; A Refers to 6 rollers; B refers to 10 rollers | 0.00025-48ml/min | |
| DG-1B | 0.0002-32ml/min | ||
| DG-2A | 0.00025-48ml/min Single channel | ||
| DG-2B | 0.0002-32ml/min Single channel | ||
| DG-4A | 0.00025-48ml/min Single channel | ||
| DG-4B | 0.0002-32ml/min Single channel |
Special designed carton and foam plastic cushion
Professional bundling machine ensure safe delivery to customers directly .
These precise instruments are mainly delivered by Express like DHL FedEx etc.
