Product Details
Place of Origin: Hebei, China
Brand Name: Huiyu
Certification: RoHS
Model Number: BT100J-2A
Payment & Shipping Terms
Price: $100.00 - $500.00/sets
Packaging Details: 1 pump in 1 carton with foam plastic
Supply Ability: 1000 Set/Sets per Week
Warranty: |
1 Year |
Customized Support: |
OEM |
Application: |
Food And Beverage Industry, Laboratory |
Horsepower: |
100rpm |
Power Source: |
Electric |
Pressure: |
Low Pressure |
Structure: |
Peristaltic Pump |
Type: |
BT100J-2A |
Motor: |
Stepper Motor |
Max Flow Rate: |
380ml/min |
Certificate: |
CE RoHS |
Communication: |
RS485 |
Warranty: |
1 Year |
Customized Support: |
OEM |
Application: |
Food And Beverage Industry, Laboratory |
Horsepower: |
100rpm |
Power Source: |
Electric |
Pressure: |
Low Pressure |
Structure: |
Peristaltic Pump |
Type: |
BT100J-2A |
Motor: |
Stepper Motor |
Max Flow Rate: |
380ml/min |
Certificate: |
CE RoHS |
Communication: |
RS485 |
Motor speed | 0.1~100rpm Forward and reverse reversible, |
Speed resolution | 0.1 rpm |
Adjustment method | continuous adjustment of membrane button |
Display mode | 3-digit LED digital speed display |
External control interface | start and stop control, direction control, speed control (0-5V, 0-10V, 4-20mA, 0-10KHz optional) |
Applicable power supply: | AC 220V±10% 50Hz/60Hz |
Max power consumption | 30W |
Working environment | 0-40℃，relative humidity ＜80％ |
Measurement | 197 × 136 × 110 (mm) |
IP rating | IP65 |
1.Drive | 2.Pump Head | 3. 2 meters silicon tube | 4. power cord | 5. manual pamphlet | ||||
Warranty:1 year | ||||||||
