Product Details
Place of Origin: Hebei, China
Brand Name: Huiyu
Certification: RoHS
Model Number: WT600J-2A
Payment & Shipping Terms
Price: $100.00 - $500.00/sets
Packaging Details: 1 pump in 1 carton with foam plastic
Supply Ability: 1000 Set/Sets per Week
Warranty: |
1 Year |
Customized Support: |
OEM |
Application: |
Food And Beverage Industry, Pharmaceutical Industry, Water Treatment Solutions, Laboratory |
Horsepower: |
600rpm |
Power Source: |
Electric |
Pressure: |
0.2Mpa |
Structure: |
Peristaltic Pump |
Voltage: |
AC220V±20% |
Power: |
200w |
Type: |
WT600J-2A |
Motor: |
Stepper Motor |
Max Flow Rate: |
6000ml/min |
Certificate: |
CE RoHS |
Communication: |
RS485 |
Warranty: |
1 Year |
Customized Support: |
OEM |
Application: |
Food And Beverage Industry, Pharmaceutical Industry, Water Treatment Solutions, Laboratory |
Horsepower: |
600rpm |
Power Source: |
Electric |
Pressure: |
0.2Mpa |
Structure: |
Peristaltic Pump |
Voltage: |
AC220V±20% |
Power: |
200w |
Type: |
WT600J-2A |
Motor: |
Stepper Motor |
Max Flow Rate: |
6000ml/min |
Certificate: |
CE RoHS |
Communication: |
RS485 |
Motor speed | 60-600rpm |
Motor speed precision | ≤±1％ |
motor speed resolution | 1.0rpm |
Output torque | 1.5Nm |
Display | 3 digit LED for speed;4 LED indicators for working status |
Memory function | save parameter automatically |
remote control port | (0.5-5v/1-10v voltage signal,4-20mA,0-10kHz singal are optional) to control the motor speed(60-600rpm) |
Communication port | RS485 |
Power supply | AC220V±20％,50/60Hz |
Max power consumption | ≤200W |
Working environment | 0-40℃，relative humidity＜80％ |
Measurement | 250x190x255（LXWXH）mm |
Weight | 8KG |
IP rating | IP55 |
1.Drive | 2.Pump Head | 3. 2 meters silicon tube | 4. power cord | 5. manual pamphlet | ||||
Warranty:1 year | ||||||||
